Original price was: £1,185.00.£829.50Current price is: £829.50. + VAT
Command maximum-scale industrial and commercial boundaries with the elite power of the Fadini NYOTA 115 EVO 230V Single-Phase 1.0 HP Electromechanical Sliding Gate Automation Kit (VIX 53 Edition). Specifically engineered for massive commercial facilities, heavy industrial cantilever tracking, and ultra-wide estate entrances, this high-capacity configuration runs on standard single-phase mains power to effortlessly drive sliding gates weighing up to an incredible 1,850 kg.
The engineering peak of the Nyota 115 EVO 1.0 HP model is its industrial-grade oil-bath transmission. By fully submerging its high-torque steel worm screw and heavy bronze crown matrix inside a large FAD OIL 35 dielectric fluid reservoir, Fadini ensures total heat dissipation. This allows the 1.0 HP induction motor to maintain intensive continuous operation under extreme structural loads without risk of thermal cutout. This complete kit includes the built-in Elpro 12 EVO Digital Control Board for precision automatic travel calibration, paired with the highly secure VIX 53 868MHz rolling-code system to secure your facility against signal cloning.
1.0 HP Commercial-Grade Induction Motor: Power-tuned 230V single-phase motor consuming 730W to deliver a massive 80 Nm of continuous rotational torque for heavy gates up to 1,850 kg.
Permanent Fluid-Immersed Transmission: Submerges all primary internal gear components in a continuous oil bath for total friction elimination, silent operation, and industrial duty cycles.
Elpro 12 EVO Microprocessor Control: Features integrated digital encoders, automatic travel learning cycles, adjustable electronic slowdown, and non-contact magnetic limit sensors.
Upgraded VIX 53 Security Matrix: Utilizes advanced 868.19 MHz rolling-code encryption to completely prevent code grabbing, scanning, or unauthorized perimeter breeches.
Automating high-mass industrial gates or solid-faced barriers subject to high wind resistance demands an immense baseline breakaway torque. The Fadini NYOTA 115 EVO 230V Single-Phase 1.0 HP system delivers this through a heavy-duty single-phase induction motor optimized for raw pulling power. Because industrial tracking is prone to collecting debris, gravel, or ice, the 1.0 HP motor provides the critical mechanical reserve power needed to push past track imperfections that would stall lesser residential-grade operators.
The structural longevity of the system relies on its specialized oil-bath framework. The internal components operate in a self-lubricating, protective fluid layer, meaning mechanical friction and gear wear are reduced to near-zero. Controlled by the integrated Elpro 12 EVO Control Board, the system guides heavy gates smoothly through custom-calibrated travel paths, utilizing non-contact Magnetic Limit Switches to eliminate physical wear on travel ends.
Epoxy-Coated Die-Cast Chassis: Built inside an ultra-rugged die-cast aluminum tower housing designed to withstand harsh industrial environments, road salt spray, and extreme sub-zero frost.
Dual Anti-Crush Safeguards: Combines a physical, adjustable mechanical friction clutch running in the oil bath with electronic amperometric sensor monitoring to ensure safe, reactive obstacle detection.
Safe Cover Microswitch Interlock: Features a structural cut-off switch that immediately disconnects low-voltage logic operations whenever the main outer chassis cover is removed for maintenance.
Keyed Manual Emergency Release: A solid aluminum, lockable manual release lever allows instant mechanical disengagement of the oil-bath drive loop during localized power blackouts.
1x NYOTA 115 EVO 230V Single-Phase 1.0 HP Geared Motor: Featuring a heavy-duty Oil-Bath Gearbox (up to 1,850kg capacity limits).
1x Integrated Elpro 12 EVO Control Board: Digital management logic controller pre-wired inside the motor housing.
1x VIX 53/2 R Plug-In Radio Card: (Model 5311L) Advanced 868.19 MHz rolling-code frequency receiver.
2x VIX 53/4 TR 4-Button Remote Transmitters: (Model 5313SL) Modern Skyline Grey multi-channel pocket keyfobs.
1x Birio A8 Tuned Radio Antenna: (Model 4605L) High-gain external aerial to maximize remote range.
1x Pair of Orbita 57 Safety Photocells: (Model 570L) Surface-mounted infrared safety beams to secure the path of travel.
1x Anchor Base Plate & Fixing Kit: Extra-thick steel grounding plate with anchor bolts for heavy-duty industrial concrete foundations.
| System Attribute | Engineering Specification (1.0 HP Single-Phase Model) |
| Motor Power Output | 0.73 kW (1.0 HP / One Full Horsepower) |
| Mains Supply Input | 230V AC Single-Phase (50Hz) |
| Maximum Gate Weight | 1,850 kg (1.85 Metric Tonnes) |
| Absorbed Power | 730 W |
| Absorbed Current | 3.5 A |
| Motor Rotation Speed | 1,350 rpm |
| Output Torque | 80 Nm (Massive Industrial Breakaway Force) |
| Gear Reduction Ratio | 1:32 |
| Output Pinion Module | Module 4 (M4 Standard Drive Interface) |
| Gate Linear Travel Speed | 10 meters per minute |
| Lubrication Oil Volume | ~0.6 Liters (FAD OIL 35 High-Dielectric Fluid) |
| Capacitor Rating | 30 μF (Heavy-Duty Single-Phase Motor Starter Capacitor) |
| Limit Switch Typology | High-Precision Non-Contact Magnetic Sensors |
| Environmental Protection | IP44 Weatherproof Outer Structural Shell |
| Duty Cycle Frequency | Intensive Industrial Operation Profile |
| Operating Heat Range | Suitable for temperatures between -20°C up to +80°C |
Pro Tip: Due to the immense rotational mass of an 1,850kg gate, the single-phase 1.0 HP Nyota utilizes a large 30 microfarad (μF) starting capacitor to generate the initial 80 Nm phase-shift torque required to move the gate from a dead stop.
The Professional Method: During cold-weather commissioning or winter handovers, if a heavy gate struggles to start or if the Elpro 12 EVO board trips an error code on start-up, check your mains voltage drop. Running a long, undersized supply cable (e.g., long runs of 1.5mm² cable) to a remote perimeter gate causes a voltage drop when the 3.5A motor kicks in, lowering the capacitor’s energy capacity. Always supply a 1.0 HP unit with a minimum of 2.5mm² Steel Wire Armored (SWA) cable to guarantee stable voltage supply and full torque performance.
