Original price was: £1,976.00.£1,383.20Current price is: £1,383.20. + VAT
Command exceptional fluid-driven power, flawless wind resistance, and pristine digital security across large entranceways with the Fadini HINDI 880 EVO (K880.2L) Long-Stroke Hydraulic Double Gate Automation Kit (VIX 53 Edition). Built for demanding residential estates, commercial entries, and wind-exposed perimeters, this heavy-duty system is configured with premium 400mm extended-stroke rams explicitly designed to handle wide double swing gates up to 4.0 meters per leaf (or up to 550kg in weight).
The K880.2L long-stroke configuration provides maximum leverage, making it the absolute gold standard for wide close-boarded timber or industrial steel gates. Moving away from standard mechanical gears, its high-pressure oil-hydraulic design delivers silent, smooth travel and inherently dampens sudden wind impacts. Managed by the reliable Elpro 27 Control Panel, safety is physically integrated via twin internal brass by-pass valves for precision mechanical anti-crushing control. Upgraded with the VIX 53 868MHz radio receiver, this package provides uncopyable 128-bit security alongside adjustable multi-mode EVO hydraulic locking.
Extended 400mm Long-Stroke Rams: Delivers increased mechanical advantage and smooth control over wide gate leaves up to 4.0 meters.
EVO Valve Flexibility: Allows installers to quickly adjust physical locking parameters on the ram chassis: set for bidirectional locking, single-point locking, or fully reversible modes.
Integrated By-Pass Safety: Dual precision hydraulic relief valves regulate pressure directly at the pump, providing premium anti-crush sensitivity.
Upgraded VIX 53 Radio Matrix: Operates on advanced 868.19 MHz rolling-code frequencies to eliminate the risk of digital signal copying or unauthorized vehicle access.
Automating wide gates or those mounted on deep stone pillars requires substantial leverage that standard short-arm operators simply cannot provide. The Fadini HINDI 880 EVO K880.2L system solves this limitation with its 400mm industrial-grade piston travel. By utilizing a continuous low-viscosity fluid loop inside a premium extruded anodized aluminum housing, the rams generate immense linear thrust directly across the gate structure, effortlessly conquering crosswinds without the mechanical wear or grinding noises associated with traditional screw-driven rams.
Versatility is central to the Hindi 880 Evo design. Its integrated EVO Valve Technology lets you customize the physical locking profile directly under the ram’s protective lid. It can be easily set up to lock rigidly in the closed position (B Mode), lock in both open and closed positions (BB Mode), or remain completely reversible (N Mode) for manual operation paired with an external electric lock. Driven by the field-tested Elpro 27 Logic Board, the kit guarantees uniform speed throughout its opening cycle.
Anodized Corrosion Shield: The structural outer body is constructed from high-grade extruded anodized aluminum, guaranteeing immunity against harsh winter frost, high humidity, and road salt.
Fluid Deceleration Braking: Features internal hydraulic dampening channels that provide built-in hydraulic braking zones near the end of travel, eliminating harsh gate slamming.
Adjustable Ball Bearing Collar: Equipped with a heavy-duty adjustable rear mounting joint that allows installers to fine-tune geometry configurations on uneven brick or stone pillars.
Ergonomic Release Mechanism: Includes a dedicated, customized metal override key located under a weatherproof protective sliding flap, allowing instant manual gate release during power cuts.
2x HINDI 880 EVO Long-Stroke Hydraulic Operators: (Model 890P5L) 230V AC Hydraulic Rams with Extended 400mm Stroke.
1x Elpro 27 Control Panel Box: (Model 7047L) Reliable, tried-and-tested mains management logic controller.
1x VIX 53/2 R Plug-In Radio Card: (Model 5311L) Advanced 868.19 MHz rolling-code frequency receiver.
2x VIX 53/4 TR 4-Button Remote Transmitters: (Model 5313SL) Modern Skyline Grey multi-channel pocket keyfobs.
1x Birio A8 Tuned Radio Antenna: (Model 4605L) Maximizes remote control operational range.
1x Pair of Orbita 57 Safety Photocells: (Model 570L) Active surface-mounted infrared beams to safeguard vehicles and pedestrians.
2x Pin & Bracket Mounting Sets: Extra-strong weldable steel rear post and front gate brackets.
| System Attribute | Engineering Specification |
| Kit Model Code | K880.2L (Double Above-Ground Long-Stroke Hydraulic 230V Edition) |
| Radio Control Matrix | Fadini VIX 53 Rolling-Code Transceiver Protocol (868.19 MHz) |
| Working Operational Medium | High-Performance Hydraulic Oil (Fadini Grade 708L) |
| Mains Voltage Input | 230V AC Mains Powered (50Hz) |
| Max Absorbed Power | 250 W per ram |
| Max Absorbed Current | 1.2 A |
| Piston Rod Diameter | 20 mm |
| Useful Rod Stroke | 400 mm (Long-Stroke Extended Leverage) |
| Maximum Thrust Force | Up to 5,200 N (Massive Wind-Beating Pushing Power) |
| Max Capacity Limits | Up to 4.0m leaf width / Maximum 550kg weight per leaf |
| Environmental Protection | IP67 Rated Internal Pump Seals / IP44 Overall Casing |
| Duty Cycle Frequency | Very Intensive / Continuous Operating Rating |
| Operating Heat Range | Suitable for extreme temperatures between -25°C up to +80°C |
Pro Tip: Because the K880.2L kit handles wide gate leaves up to 4.0 meters, the physical surface area acts like a massive sail during high-wind events. This places immense rotational pressure on the hydraulic internal valves when the gates are held shut.
The Professional Method: Fadini dictates that for any gate leaf exceeding 2.0 meters in width, an external electric lock (such as a 12V AC/DC latch or magnetic lock) must be installed at the center-stop point. Even if you have the EVO valves configured to bidirectional hydraulic locking (BB Mode), the physical electric lock absorbs the severe mechanical leverage forces caused by wind gales or forced entry attempts. This simple addition prevents high-pressure oil from being forced past the internal by-pass valves, keeping your hydraulic pump seals perfectly sound for decades.
