Original price was: £1,820.00.£1,274.00Current price is: £1,274.00. + VAT
Bring industrial-grade reliability, ultra-smooth fluid dynamics, and elite digital protection to your property with the Fadini HINDI 880 EVO (K880.1L) Above-Ground Hydraulic Double Gate Automation Kit (VIX 53 Edition). Engineered as a heavy-duty solution for exposed residential estates, multi-user collective complexes, and industrial sites, this premium oil-hydraulic linear ram system is designed to seamlessly operate pairs of swing gates up to 2.8 meters wide per leaf (or up to a massive 550kg in weight).
The K880.1L kit features Fadini’s signature oil-hydraulic drive train, housed inside a stylish, weather-resistant extruded anodized aluminum chassis. Moving away from traditional gears, hydraulic pressure delivers silent, jerk-free movement while acting as its own shock absorber against harsh incoming winds. Managed by the classic Elpro 27 Control Panel, safety is physically integrated via twin internal brass by-pass valves that provide precise mechanical anti-crushing protection. Upgraded with the VIX 53 868MHz radio receiver, this package delivers uncopyable 128-bit digital security alongside adjustable multi-mode hydraulic physical locking.
Premium Oil-Hydraulic Engineering: Provides exceptionally smooth, silent travel and long service life with zero mechanical gear friction.
EVO Valve Versatility: Features an innovative internal valve matrix that can be configured for bidirectional physical locking, single locking, or fully reversible manual modes.
Integrated By-Pass Safety: Dual precision hydraulic relief valves regulate thrust directly at the fluid pump, offering elite mechanical anti-crush sensitivity.
Upgraded VIX 53 Radio Matrix: Employs advanced 868.19 MHz rolling-code frequencies to completely eliminate the risk of digital signal copying or unauthorized vehicle access.
When automating wide, solid-boarded timber or heavy ornamental wrought iron gates, standard electromechanical systems can struggle against wind-loading forces. The Fadini HINDI 880 EVO K880.1L system solves this using high-pressure hydraulic fluid to move a 20mm hardened steel piston rod. Because the internal pump continuously circulates specialized low-viscosity oil, the ram delivers massive linear thrust without the mechanical wear, noise, or gear-chatter associated with typical screw-driven systems.
The Hindi 880 Evo is uniquely adaptive. Its integrated EVO Valve Technology allows installers to customize the physical locking profile directly on the ram body. It can be set up to lock rigidly in the closed position (B Mode), lock in both open and closed positions (BB Mode), or remain completely reversible (N Mode) for manual operation alongside an electric lock. Controlled by the reliable Elpro 27 Logic Board, the kit provides smooth, uniform speed throughout its opening cycle.
Anodized Corrosion Shield: The exterior structural shell is constructed from high-grade extruded anodized aluminum, ensuring maximum immunity against high humidity, road salt, and harsh winter frost.
Hydraulic Deceleration Options: Engineered with internal fluid dampening channels that provide built-in hydraulic braking zones near the end of travel, preventing structural gate slamming.
Adjustable Ball Bearing Ring: Equipped with a high-strength adjustable rear mounting collar that allows fine-tuned geometry corrections on uneven brick or stone pillars.
Secure Ergonomic Release: Includes a dedicated, customized metal release key located under a weatherproof protective sliding flap, allowing instant manual gate override during power cuts.
2x HINDI 880 EVO Hydraulic Operators: (Model 880P5L) 230V AC Irreversible Hydraulic Rams with 280mm Stroke.
1x Elpro 27 Control Panel Box: (Model 7047L) Reliable, tried-and-tested mains management logic controller.
1x VIX 53/2 R Plug-In Radio Card: (Model 5311L) Advanced 868.19 MHz rolling-code frequency receiver.
2x VIX 53/4 TR 4-Button Remote Transmitters: (Model 5313SL) Modern Skyline Grey multi-channel pocket keyfobs.
1x Birio A8 Tuned Radio Antenna: (Model 4605L) Maximizes remote control operational range.
1x Pair of Orbita 57 Safety Photocells: (Model 570L) Active surface-mounted infrared beams to safeguard vehicles and pedestrians.
2x Pin & Bracket Mounting Sets: Heavy-duty weldable steel rear post and front gate brackets.
| System Attribute | Engineering Specification |
| Kit Model Code | K880.1L (Double Above-Ground Hydraulic 230V Edition) |
| Radio Control Matrix | Fadini VIX 53 Rolling-Code Transceiver Protocol (868.19 MHz) |
| Working Operational Medium | High-Performance Hydraulic Oil |
| Mains Voltage Input | 230V AC Mains Powered (50Hz) |
| Max Absorbed Power | 250 W per ram |
| Max Absorbed Current | 1.2 A |
| Piston Rod Diameter | 20 mm |
| Useful Rod Stroke | 280 mm |
| Maximum Thrust Force | Up to 5,400 N (Massive Wind-Beating Pushing Power) |
| Max Capacity Limits | Up to 2.8m leaf width / Maximum 550kg weight per leaf |
| Environmental Protection | IP67 Rated Internal Pump Seals / IP44 Overall Casing |
| Duty Cycle Frequency | Very Intensive / Continuous Operating Rating |
| Operating Heat Range | Suitable for extreme temperatures between -25°C up to +80°C |
Pro Tip: Unlike electromechanical rams that use digital control boards to limit pushing power, the Hindi 880 Evo manages force through mechanical by-pass valves located directly under the removable top valve cover.
The Professional Method: During commissioning on the Elpro 27 control board, you should adjust the red (closing force) and green (opening force) hydraulic by-pass screws on the ram body using a flat screwdriver. Turn them until you find the perfect balance where the gate easily moves through normal wind resistence, but can still be safely stopped by hand if it encounters a person or vehicle. For gates wider than 2.0 meters, even if using the hydraulic locking version, always install an electric gate lock to shield the internal hydraulic valves from structural leverage spikes caused by heavy wind gusts or forced entry attempts.
