Fadini Zero.K Keyswitch

Original price was: £63.00.Current price is: £50.40. + VAT

RECESS AND SURFACE MOUNT KEYSWITCH

SKU zero.k Categories , Tags , , , , , , Brand:

Description

KEY-SWITCHES SURFACE AND RECESS MOUNT
Automatic return lock: standard cylinder

TOP SECURITY
Metal alloy body, powder coated and highly resistant to atmospheric agents. Opening only by key once inserted. Incorporated electronic card, complete with terminals and NO and NC contacts. Compact size and dimensions: 23 mm minimum jutting from surface line level with the recess version.

WHEN DESIGN CAN ILLUMINATE
Back-illuminated, luminous frame by a white led. Complete line of posts and fixing supports.

Data Sheet:-

  • Power supply (Vac/dc)
    24
  • Absorption (mA)
    max 10
  • Working temperature (°C)
    -30 ÷ +70
  • Microswitches contact
    gold triple coating
  • Microswitches max. load (mA – Vdc)
    100 – 30
  • Grade of protection IP
    54

Additional information

Mounting

Surface Mounted, Recess Mounted
